Mitutoyo 500-196-30 Digital Caliper, 0-150mm / 0-6" Range, Digimatic, Resolution 0.01mm / 0.0005", Absolute System
SKU:Code: 500-196-30
The UKs Leading Metrology Distributor
Trusted by the biggest companies in the UK
Need more information? Ask a question or contact us.
- brand Mitutoyo
- type Standard
- range 0-150mm / 0-6"
- display type Digital
- resolution 0.01mm / 0.0005"
- data output No
- measuring units Metric / Imperial
- max permissible errors E MPE ±0.001" / S MPE ±0.002"
- power supply Low Voltage Alarm
- battery life 5 Years under normal use
- mass 168g
- battery SR44
- abs measure system Yes
- power supply Low Voltage Alarm
- calibration Comes with Certificate of Inspection
- remarks Including box
- bluetooth No
- max response speed Unlimited
- depth bar Flat Blade
- origin seting Yes
- series CD-6”ASX
- calibration Comes with Certificate of Inspection
- hs code 90173000000
- country of origin Japan
Mitutoyo 500-196-30 ABS Digital Caliper – 150mm / 6" Range
The Mitutoyo 500-196-30 ABS Digital Caliper is a professional-grade measuring tool designed for accuracy, reliability, and ease of use. Ideal for engineers, machinists, and quality inspectors, this 150mm (6") digital caliper delivers fast, repeatable measurements without the need for constant re-zeroing.
Mitutoyo’s ABSOLUTE linear encoder technology retains the origin position even when the caliper is powered off, eliminating cumulative errors and improving workflow efficiency during repetitive measurements.
Key Features
- ABSOLUTE linear encoder eliminates the need for re-zeroing
- ZERO/ABS function allows comparative and absolute measurements
- Measurement range of 0–150mm (0–6")
- Accuracy of ±0.02mm with 0.01mm resolution
- Large, clear LCD display for quick, easy readings
- Up to 20,000 hours of battery life for long-term reliability
- Smooth slider movement for comfortable, controlled operation
- Measures outside, inside, depth, and step dimensions
Applications
- Precision engineering
- Machining and CNC workshops
- Quality control and inspection
- Toolrooms and manufacturing environments
Free Caliper Stand
For a limited time, receive a free caliper stand with order containing a 500-196-30. The stand provides a practical and secure storage solution when the caliper is not in use. One stand per order, while stocks last.
Why Choose the Mitutoyo 500-196-30
Trusted worldwide, Mitutoyo calipers are known for consistent accuracy and long service life. The 500-196-30 combines proven ABS technology with robust construction, making it a dependable choice for professional measurement tasks.
