With its Pasty initial consistency (modelling clay), the LC-AD can be applied manually on vertical or overhead surfaces.
The final impression is Semi-Rigid (90 Shore A hardness), and cannot be deformed ans strectched. It does not accept any Removal Constraint, and should be used only on simple forms. The LC-AD is recommended for taking rigid impressions of external simple forms on parts of large or medium sizes.
It can also be used to temporarily add strength to fragile parts before machining, to avoid vibrations.
The LC-AD is suitable for the following applications :
- External impressions of simple forms
- Add strength to fragile parts before machining
Because the impression is soft and very flexible, it is controlled without contact, using a visual measuring instrument (profile projector, microscope, optical measuring instrument...).
But the best way to control it is to use the Plastiform® Twin Blade Cutter to create a slice, and measure the dimensions of the slice on a profile projector.
Curing Time : 4 minutes
Removal Constraint : 0 %
Elongation to Failure : 0 %
|Curing Time||4 Mins|
|Final Hardness Shore A||90|
|Suitable for Contact Measuring||Yes|
|Suitable for use with Double Blade Cutter||Yes|
Plastiform Product Code MT-004
Initial Consistency : Malleable
Final Consistency : Semi-Rigid
Hardness : 90 Shore A
Accuracy of the impression : µm
Cut with Twin Blade Cutter : Yes
