90-TP-5-3-40 Tapered Thread Form Profile Gage, 2⅜” - 4½” API REG 2⅞”, 3½”, 4½” API Full Hole, 5 TPI, 3” TPF, V-0.040
SKU:Code: 90-TP-5-3-40
Sale
Sold out
Regular price
£186.71
Save: 3%
Sold out
Sale price
£186.71
Regular price
£191.50
Excl. VAT
Gagemaker manufactures precision tapered thread profile gages for the quick identification of product thread forms. Specify the connection which is to be inspected when ordering.
The UKs Leading Metrology Distributor
Trusted by the biggest companies in the UK
Need more information? Ask a question or contact us.
Specification
Specification
- type Thread Profile Gauges
description
description
Thread form accuracy is important if two connections are to make-up properly. Using a Thread Profile Gage provides a quick check of the thread to ensure that the form is correct. The Thread Profile should be used on every connection to ensure the first imperfect thread was deburred fully. Thread form is defined as its profile in an axial plane for a length of one pitch. Most importantly, verifying thread form is a recommended inspection for API connections and ensures form accuracy.
