Insize QMS-A110 Field of view inspection machine, Measuring Range Ø100 x 80mm, Includes PC and Software
SKU:Code: QMS-A110
The INSIZE QMS-A110 is a compact, high-precision quick measurement system designed for rapid 2D inspection of small flat parts.
It features a low-distortion telecentric lens with a 100 × 80 mm view field, offering a measurement range of 98 × 78 mm with ±3 μm accuracy and ±1 μm repeatability.
Workpieces (up to 5 kg) can be freely placed and measured in under two seconds, with automatic focusing.
The system includes a green telecentric backlight, multi-zone ring light, optional coaxial illumination, and comes with a computer and software package.
Measuring just 580 × 235 × 790 mm and weighing around 40 kg, it is suited to controlled environments (20 °C ± 2 °C, 30–80 % RH) and is widely used for fast, repeatable quality control.
The UKs Leading Metrology Distributor
Trusted by the biggest companies in the UK
Need more information? Ask a question or contact us.
- range Field of View Range Ø100 x 80
- accuracy ± 3μm
- remarks Includes PC and Software
- remarks Max Load 5kg
- repeatability ± 1μm
- lens ø100mm Telecentric lens
- brand Insize
- lens ø100mm Telecentric lens
The INSIZE QMS-A110 is a precision quick measurement system engineered for fast and accurate 2D inspection of small flat parts. Its design allows operators to place components freely on the measuring stage without special positioning, making it ideal for high-throughput quality control processes.
At the core of the QMS-A110 is a low-distortion telecentric lens with a 100 × 80 mm view field. This enables a measurement range of 98 × 78 mm, delivering an impressive accuracy of ±3 μm and repeatability of ±1 μm. The system can measure multiple parts in one go, saving significant time on repetitive inspection tasks.
Measurement speed is one of its key advantages, capturing results in under two seconds. The device automatically focuses and processes data, ensuring consistency even with operator variation. It supports workpieces up to 5 kg, making it suitable for a wide range of precision components.
Illumination is provided by a telecentric green backlight and a 4-zone white ring light, with optional coaxial and vertical lighting for more challenging geometries. This flexibility allows clear edge detection and accurate results even for complex shapes.
Compact and robust, the QMS-A110 measures 580 × 235 × 790 mm and weighs around 40 kg. It operates best in controlled conditions (20 °C ± 2 °C, 30–80 % relative humidity) and comes supplied with a computer and software package, making it a ready-to-use solution for modern inspection environments.
