Mitutoyo 500-172-30 Digimatic Digital Caliper, Range 0 - 200mm / 0 - 8", Resolution 0.01mm / 0.0005", Absolute System and SPC Data Output
SKU:Code: 500-172-30
The UKs Leading Metrology Distributor
Trusted by the biggest companies in the UK
Need more information? Ask a question or contact us.
- brand Mitutoyo
- type Standard
- range 0-200mm / 0-8
- display type Digital
- resolution 0.01mm / 0.0005"
- data output Yes
- measuring units Metric / Imperial
- depth bar Flat Blade
Mitutoyo 500-172-30 Digimatic Digital Caliper – 0-200mm / 0-8", 0.01mm / 0.0005" Resolution with SPC Data Output
The Mitutoyo 500-172-30 Digimatic Digital Caliper is a precision measuring instrument designed for accurate dimensional measurement and direct data capture. With a 0-200 mm (0-8") range and integrated SPC data output capability, it is ideal for quality control, inspection, and process monitoring applications where measurement data needs to be recorded or analysed.
Equipped with Mitutoyo’s ABSOLUTE linear encoder technology, this caliper retains its origin position even when powered off, eliminating the need for repeated zero setting and allowing immediate measurement when switched on. The large LCD display and smooth slider movement ensure clear readability and comfortable use.
Key Features
- ABSOLUTE linear encoder eliminates the need for origin resetting
- Integrated SPC data output for direct measurement capture
- Measuring range of 0-200mm / 0-8"
- Resolution of 0.01mm / 0.0005"
- Large, clear LCD display for fast, reliable readings
- Smooth slider movement for controlled, comfortable operation
- Measures outside, inside, depth, and step dimensions
- Long battery life for extended everyday use
- Durable stainless steel construction
Applications
- Quality control and inspection
- Statistical process control (SPC)
- Precision engineering and manufacturing
- Toolrooms and workshop measurement tasks
Why Choose the Mitutoyo 500-172-30
The Mitutoyo 500-172-30 combines precise digital measurement with direct data output, making it a practical and efficient choice for environments where measurement data must be captured, analysed, or recorded. Its trusted ABS technology, clear digital display, and robust construction make it a dependable tool for professional measurement tasks.
