Mitutoyo 542-197 LG100 Coolant Proof Linear Gauge, Range 50mm, Resolution 0.001mm
SKU:Code: 542-197
The UKs Leading Metrology Distributor
Trusted by the biggest companies in the UK
Need more information? Ask a question or contact us.
- brand Mitutoyo
- type Linear Gauge LG100
- range 50mm
- graduations 0.0005mm
High-accuracy gauge head suitable for in-line and in-laboratory use. Assures the expected repeatability (2σ) in the full measurement range and the narrow-range precision. Protection grade IP67G with sliding durability of 50 million times and more*1 and adoption of highly oil-resistant materials. All models have the origin point signal output function to restore the origin point position after recovery from problems such as overspeed. It can be connected to a compact counter (EJ counter) suitable for in-line use or building into a device or a multifunctional counter (EH counter)*2 suitable for use in measurement rooms.
| Model: |
LG100-0550
|
| Range: |
0–50 mm
|
| Accuracy: |
(1.5+L/50) μm
L=measured length in mm |
| Measuring force: |
5.7 N with spindle down,
5.3 N with spindle horizontal, 4.9 N with spindle upwards |
| Resolution: |
0.0005 mm
|
| Stem ∅: |
15 mm
|
| Cable length: |
2 m
|
| Scale: |
Photoelectric linear encoder
|
| Max. response speed: |
1500 mm/s
|
| Contact point: |
Ø3 mm carbide ball, thread: M 2.5 x 0.45
|
| Output signal: |
90° phase difference, differential square wave (RS-422 equivalent)
|
| Environmental conditions: |
0°C to 50°C (20% to 80% rel. humidity, no condensation) °C
|
| Bearing type: |
Linear ball bearing
|
| Signal pitch: |
2 µm
|
| Power supply: |
DC 5 V ±0.2 V ripple voltage200 mVpp max
|
| Minimum edge distance: |
500 ns (1 μm type),
250 ns (0.5/0.1 μm type) |
| Scale reference point: |
3 mm from the lowest rest point
(10 mm type), 5mm from the lowest rest point (25/50 mm type) |
| Mass: |
400 g
|
