- type Linear Gauge LGH-1010C-B-EH
- range 10mm
- graduations 0.00001mm
This series has achieved very high accuracy combined with a resolution of 0.01/0.005 μm (according to model), practically equivalent to that of a laser interferometer, and a wide measuring range of 10 mm. A compact body design makes a significant contribution to a downsizing of this gauge itself, which is best suited for calibration/evaluation of master gauges as well as measurement of high-precision parts and as a length measuring sensor incorporated into high-precision positioning/control units. A low measuring force model is available for those applications where measurement of easily deformed or damaged workpieces is required. Every LGH Series gauge is bundled with a dedicated counter. This model is equipped with a newly developed optical reflection-type linear encoder, achieving an excellent resolution of 0.01 µm, a measuring accuracy of 0.2 µm and a measuring range of 10 mm at a low price. Maximum operating speed has been improved by a factor of 2.8 times (250 → 700 mm/s) while maintaining very high accuracy.
