Mitutoyo

543-311B-10 Absolute Digimatic Digital Bore Gauge Indicator ID-C, Range 0.5" / 12.7mm, Resolution 0.00005", 0.0001", 0.0005" / 0.001mm, 0.01mm ( Selectable )

SKU:Code: 543-311B-10

Sale Sold out Regular price £372.00
Save: 25% Sold out Sale price £372.00 Regular price £496.00
Excl. VAT
Exclusively designed for Bore Gauges: this ID-C series indicator has the minimum value holding and GO/NO-GO judgement functions.
  • The UKs Leading Metrology Distributor

  • Trusted by the biggest companies in the UK

  • Need more information? Ask a question or contact us.

View full details
Specification
  • range 0.5" / 12.7mm
  • display type Digital
  • data output Yes
  • ip rating IP42
  • measuring units Imperial / Metric
  • stem dia 8mm
  • contact point thread M2.5 x 0.45
  • back Flatback
description

Exclusively designed for Bore Gauges: this ID-C series indicator has the minimum value holding and GO/NO-GO judgement functions. Employing an ABSOLUTE Linear Encoder, the Bore Gauge ID-C always displays the absolute position of the plunger from the origin at power-on. Also, the reliability has been increased due to elimination of over-speed errors. An analogue bar indication is integrated to provide the advantages of analogue display for minimum value measurements. Up to three sets of reference diameter and upper/lower tolerance values can be stored to simplify the start-up key operation in repetitive hole inspection of mixed-diameter holes. Equipped with a data output port that enables incorporation into measurement networking and statistical process control systems.
