Mitutoyo
573-281-30 Digimatic Digital Snap Caliper, Range 0-100mm / 0-4", Resolution 0.01mm / 0.0005", Absolute System and SPC Data Output
SKU:Code: 573-281-30
The UKs Leading Metrology Distributor
Trusted by the biggest companies in the UK
Need more information? Ask a question or contact us.
- type Snap
- range 0-100mm / 0-4"
- display type Digital
- resolution 0.01mm / 0.0005"
- data output Yes
- measuring units Metric / Imperial
Features a 'snap action' movement control of the slider via a spring-loaded mechanism attached to a movable clamp on the beam. Enables quick and efficient repetitive GO/NO-GO inspection of a specific dimension on mass produced parts by just moving a lever. Can measure outside and inside dimensions, depth, and steps. Measuring force: 7 - 14 N (700 - 1400 gf). The slider can be retracted by up to 2 mm from the measuring position.Features Mitutoyo's ABSOLUTE system. No need to reset the origin after switching on. Slider operation is smooth and comfortable. Data output function allows integration into statistical process control and measurement systems.
