Sauter FH50 Digital Force Gauge 0-50N Range, 0.01N Resolution, with Graphic assisted Display for Tensile and Compressive Force Measurement
SKU:Code: FH50
Sale
Sold out
Regular price
£531.00
Save: 10%
Sold out
Sale price
£531.00
Regular price
£590.00
Excl. VAT
Universal digital force gauge for tensile and compressive force measurements with integrated load cell
The UKs Leading Metrology Distributor
Trusted by the biggest companies in the UK
Need more information? Ask a question or contact us.
Specification
Specification
- brand Sauter
- range 0-50 N
- resolution 0.01 N
- remarks Peak Hold = Yes
- power supply Power supply & battery included
- power supply Power supply & battery included
description
description
- Turnable display with backlight
- Can be mounted on all SAUTER test stands up to 5 kN
- NEW: USB interface for data transfer and power supply as standard
- Data interface RS-232 as standard
- Selectable measuring units: N, kgf, lbf
- Peak-Hold function to capture the peak value or Track function for continuous display of measurement
- Measuring with tolerance range (limit-setting function): Upper and lower limit adjustable, in pull and push direction. The process is supported by an audible and visual signal
- Auto-Power-Off
- Internal memory for up to 10 measurement values
- Mini Statistics Kit: calculates the average result from up to 10 stored measured values, as well as min., max., n
- Standard attachments as shown, extension rod: 90 mm, included with the delivery
- Delivered in a robust carrying case
