Tesa

01810012 Tesatast Lever Dial Indicator Parallel Type, Graduation 0.02mm, Range 2mm, Scale 0-1.0-0, Stylus Length 36.53mm, Bezel Diameter 38mm

SKU:Code: Tesa-01810012

Sale Sold out Regular price £210.40
Save: 20% Sold out Sale price £210.40 Regular price £263.00
Excl. VAT
Dial test indicator with dial face mounted parallel to the axis of the measuring insert but on the flat side of the dial housing
  • The UKs Leading Metrology Distributor

  • Trusted by the biggest companies in the UK

  • Need more information? Ask a question or contact us.

View full details
Specification
  • type Parallel Type
  • range 2.0mm
  • display type Non-Digital
  • graduations 0.02mm
  • bezel dia 38mm
  • measuring force 0.06 N
  • measuring units Metric
  • scale 0-1.0-0
  • contact point thread M1.4
  • repeatability limit 4 µm
description

These lever type dial test indicators are especially intended for use on the shop floor or in the inspection room. Ideally suited for comparative measuements on a surface plate for instance
